Cryo TEM-Talos F200C

The Thermo Fisher Scientific (former FEI) Talos F200C scanning/transmission electron microscope (S/TEM) is a powerful, versatile system for delivering 3D characterization of biological, materials science, and nanotechnology research. The system’s constant-power (C-TWIN) lens delivers outstanding optical performance to help ensure an optimal balance between contrast and resolution.

Designed for room and cryogenic temperature applications, Talos F200C enables experimentation spanning the complete application range—from TEM observation and STEM imaging to Low Dose applications and diffraction analysis.

Specifications:

S-FEG Schottky electron source
High voltage range 20 – 2000 kV (aligned at 200 kV)
High tilt (±70̊) and large field of view
TEM point resolution: 0.30 nm
TEM information limit: 0.18 nm
STEM HAADF resolution: 0.21 nm
TEM magnification range: 25x–650kx
Low-Dose Exposure Technique
Ceta 16M CMOS 16-megapixel 4k×4k digital camera with 14×14 μm2 pixel sensor
Phase plate for improved in-focus phase contrast in the image plane
High-Angle, Annular Dark Field detector (HAADF) for STEM imaging
On-axis Bright-Field/Dark-Field Detector for STEM imaging
Single tilt, double tilt, tomography single tilt and single tilt liquid nitrogen cryo transfer 70 degree Gatan holders are available
TEM Tomography data acquisition software and Inspect3D / Amira software for post data processing

Click here to visit the manufacturer’s web site

Location: Building 51, Room 008
